Product Code: YH23928
Product Name: 70g Thermal Transfer Paper/Acrylic/60g White Glassine
1. Face Stock: Thermal Transfer Paper
Caliper (μm). 67±5% GB/T 451.3-2003
Weight (g/㎡): 69±5% GB/T 451.2-2002
2. Adhesive Performance: Acrylic
Initial Adhesion (N): 10.72 FTM 9
20 min.180'Peel Adhesion (N/25mm) : 12.25 FTM 1
20 min.90'Peel Adhesion (N/25mm): 10.06/Material tore off FTM 2
Storage Temperature: -15°C to 70°C
Minimum Lakelling Temperature: 10°C
3. Liner: White Glassine
Caliper (μm): 52±5% GB/T 451.3-2003
Weight (g/㎡): 60±5% GB/T 451.3-2003
It can be stored for 1 year at the temperature of 23+2'C and relative humidity of 50+5%
Our Durable Thermal Transfer Self Adhesive Paper Rolls are engineered for high-performance labeling in demanding industrial and logistics environments. The label features a 100gsm thermal transfer-specific face stock with a proprietary ceramic-copper coating, optimized to absorb heat from thermal print heads and produce crisp, permanent images without ribbon degradation. The base material combines natural wood pulp with synthetic fibers, enhancing tensile strength while maintaining excellent ink receptivity for both thermal transfer and direct thermal printing (with optional coatings).
A permanent rubber-based adhesive ensures robust bonding to corrugated cardboard, plastic, and metal surfaces, while a 90gsm glassine release liner with siliconized coating enables smooth unwinding on high-speed automated labelers. These rolls are ideal for applications requiring long-lasting barcode legibility and resistance to abrasion, making them a staple in supply chain management and asset tracking.
Advanced Thermal Transfer Performance: The ceramic-copper coating reduces print head wear by 30% and enables consistent image formation at speeds up to 15 inches per second, compatible with wax, wax/resin, and pure resin ribbons.
Industrial-Grade Durability: Withstands 500+ rub cycles (ASTM D2228) and resists fading from UV exposure for 12+ months outdoors, outperforming standard thermal papers in harsh warehouse conditions.
Temperature Resilience: Maintains adhesive integrity and print quality between -40°C (freezer storage) and 120°C (short-term engine exposure), making it suitable for cold chain logistics and industrial equipment labeling.
Universal Substrate Adhesion: The rubber-based adhesive bonds effectively to low-energy surfaces like HDPE and PP, with a peel strength of 8N/25mm on stainless steel, minimizing label lift during handling.
Large Format Efficiency: Available in jumbo rolls up to 600mm width and 3000ft length, reducing downtime from roll changes in high-volume labeling operations.
Logistics and Warehousing: Ideal for pallet labels, shipping carton barcodes, and inventory tags, ensuring scannable data through dust, moisture, and mechanical stress.
Industrial Equipment: Used for asset tags on machinery, control panels, and tools, resisting oil, grease, and frequent cleaning with industrial solvents.
Cold Chain Management: Suitable for labeling frozen food packages, pharmaceutical cold storage, and medical specimens, maintaining print clarity through repeated freeze-thaw cycles.
Retail Distribution: Perfect for price tags, shelf labels, and product identifiers in high-traffic environments, withstanding handling wear and exposure to fluorescent lighting.
Q: Can this paper be used with direct thermal printers?
A: Yes, a direct thermal-compatible variant is available with a heat-sensitive topcoat, eliminating the need for ribbons in basic labeling applications.
Q: What is the minimum print resolution?
A: The surface supports resolutions as low as 203 DPI for standard barcodes and up to 600 DPI for high-definition graphics and micro-text.
Q: How long does the printed image last in direct sunlight?
A: With UV-resistant ribbon, the image remains legible for 18+ months outdoors. For maximum longevity, consider adding a protective laminate.
Q: Is the adhesive removable without residue?
A: The standard adhesive is permanent, but we offer repositionable adhesive options for temporary labeling needs, ensuring clean removal from most surfaces.
Product Code: YH23928
Product Name: 70g Thermal Transfer Paper/Acrylic/60g White Glassine
1. Face Stock: Thermal Transfer Paper
Caliper (μm). 67±5% GB/T 451.3-2003
Weight (g/㎡): 69±5% GB/T 451.2-2002
2. Adhesive Performance: Acrylic
Initial Adhesion (N): 10.72 FTM 9
20 min.180'Peel Adhesion (N/25mm) : 12.25 FTM 1
20 min.90'Peel Adhesion (N/25mm): 10.06/Material tore off FTM 2
Storage Temperature: -15°C to 70°C
Minimum Lakelling Temperature: 10°C
3. Liner: White Glassine
Caliper (μm): 52±5% GB/T 451.3-2003
Weight (g/㎡): 60±5% GB/T 451.3-2003
It can be stored for 1 year at the temperature of 23+2'C and relative humidity of 50+5%
Our Durable Thermal Transfer Self Adhesive Paper Rolls are engineered for high-performance labeling in demanding industrial and logistics environments. The label features a 100gsm thermal transfer-specific face stock with a proprietary ceramic-copper coating, optimized to absorb heat from thermal print heads and produce crisp, permanent images without ribbon degradation. The base material combines natural wood pulp with synthetic fibers, enhancing tensile strength while maintaining excellent ink receptivity for both thermal transfer and direct thermal printing (with optional coatings).
A permanent rubber-based adhesive ensures robust bonding to corrugated cardboard, plastic, and metal surfaces, while a 90gsm glassine release liner with siliconized coating enables smooth unwinding on high-speed automated labelers. These rolls are ideal for applications requiring long-lasting barcode legibility and resistance to abrasion, making them a staple in supply chain management and asset tracking.
Advanced Thermal Transfer Performance: The ceramic-copper coating reduces print head wear by 30% and enables consistent image formation at speeds up to 15 inches per second, compatible with wax, wax/resin, and pure resin ribbons.
Industrial-Grade Durability: Withstands 500+ rub cycles (ASTM D2228) and resists fading from UV exposure for 12+ months outdoors, outperforming standard thermal papers in harsh warehouse conditions.
Temperature Resilience: Maintains adhesive integrity and print quality between -40°C (freezer storage) and 120°C (short-term engine exposure), making it suitable for cold chain logistics and industrial equipment labeling.
Universal Substrate Adhesion: The rubber-based adhesive bonds effectively to low-energy surfaces like HDPE and PP, with a peel strength of 8N/25mm on stainless steel, minimizing label lift during handling.
Large Format Efficiency: Available in jumbo rolls up to 600mm width and 3000ft length, reducing downtime from roll changes in high-volume labeling operations.
Logistics and Warehousing: Ideal for pallet labels, shipping carton barcodes, and inventory tags, ensuring scannable data through dust, moisture, and mechanical stress.
Industrial Equipment: Used for asset tags on machinery, control panels, and tools, resisting oil, grease, and frequent cleaning with industrial solvents.
Cold Chain Management: Suitable for labeling frozen food packages, pharmaceutical cold storage, and medical specimens, maintaining print clarity through repeated freeze-thaw cycles.
Retail Distribution: Perfect for price tags, shelf labels, and product identifiers in high-traffic environments, withstanding handling wear and exposure to fluorescent lighting.
Q: Can this paper be used with direct thermal printers?
A: Yes, a direct thermal-compatible variant is available with a heat-sensitive topcoat, eliminating the need for ribbons in basic labeling applications.
Q: What is the minimum print resolution?
A: The surface supports resolutions as low as 203 DPI for standard barcodes and up to 600 DPI for high-definition graphics and micro-text.
Q: How long does the printed image last in direct sunlight?
A: With UV-resistant ribbon, the image remains legible for 18+ months outdoors. For maximum longevity, consider adding a protective laminate.
Q: Is the adhesive removable without residue?
A: The standard adhesive is permanent, but we offer repositionable adhesive options for temporary labeling needs, ensuring clean removal from most surfaces.
The 70g thermal transfer paper is compatible with thermal transfer printers, producing sharp, durable text and barcodes for long-lasting readability.
The acrylic adhesive ensures reliable bonding to various surfaces, even in challenging environments.
The 60g white glassine liner provides excellent moisture resistance and protects the adhesive during storage and handling.
It is an ideal product for high-quality heat transfer printing due to its excellent ink absorption properties of the coating on the surface. Suitable for a variety of high definition, high density bar code heat transfer printing. Most wax bases, wax and resin mixed ribbons are suitable for this product. Typical applications: White Glassine warehousing, address and shelf labels.
The 70g thermal transfer paper is compatible with thermal transfer printers, producing sharp, durable text and barcodes for long-lasting readability.
The acrylic adhesive ensures reliable bonding to various surfaces, even in challenging environments.
The 60g white glassine liner provides excellent moisture resistance and protects the adhesive during storage and handling.
It is an ideal product for high-quality heat transfer printing due to its excellent ink absorption properties of the coating on the surface. Suitable for a variety of high definition, high density bar code heat transfer printing. Most wax bases, wax and resin mixed ribbons are suitable for this product. Typical applications: White Glassine warehousing, address and shelf labels.
The coated surface material can be pre-printed with dots, negative text and solids using flexographic plates and relief plates. The viscosity of the ink should be controlled to avoid excessive viscosity of the ink causing the coating to fall off. Do not print or apply varnish to the area on the label that needs to be printed during pre-printing. Its excellent paper processing performance is suitable for rotary and flat processing methods.
The coated surface material can be pre-printed with dots, negative text and solids using flexographic plates and relief plates. The viscosity of the ink should be controlled to avoid excessive viscosity of the ink causing the coating to fall off. Do not print or apply varnish to the area on the label that needs to be printed during pre-printing. Its excellent paper processing performance is suitable for rotary and flat processing methods.
