Product Code: YH20590
Product Name: 75μ Thermal White PP/Acrylic/60g White Glassine
1. Face Stock: Thermal White PP
Caliper (μm). 73±5% GB/T 451.3-2003
Weight (g/㎡): 57±5% GB/T 451.2-2002
2. Adhesive Performance: Acrylic
Initial Adhesion (N): 13.19 FTM 9
20 min.180'Peel Adhesion (N/25mm) : 9.62/10.45 FTM 1
20 min.90'Peel Adhesion (N/25mm): 8.41 FTM 2
Storage Temperature: -15°C to 70°C
Minimum Lakelling Temperature: 10°C
3. Liner: White Glassin
Caliper (μm): 52±5% GB/T 451.3-2003
Weight (g/㎡): 60±5% GB/T 451.3-2003
It can be stored for 1 year at the temperature of 23+2'C and relative humidity of 50+5%
The Thermal Self Adhesive Barcode Label Jumbo Roll Paper is optimized for high-efficiency barcode printing in large-scale logistics and inventory management systems. The label features a 80gsm thermal-sensitive face stock with a uniform coating that ensures consistent barcode density (≥1.5 OD) and contrast (≥70%) across the entire roll. A permanent acrylic adhesive provides reliable bonding to cardboard, plastic, and metal, while a 100gsm high-release liner minimizes jamming in high-speed thermal printers.
Available in jumbo rolls up to 1000mm width and 5000ft length, this material reduces operational downtime by maximizing label yield per roll, making it ideal for distribution centers and manufacturing facilities.
Barcode Optimization: The thermal coating meets GS1 barcode standards for scannability, with a print contrast ratio that ensures first-pass read rates >99.9% in automated scanning systems.
Jumbo Roll Efficiency: Contains 3-5 times more labels than standard rolls, reducing roll change frequency and improving productivity in 24/7 labeling operations.
Abrasion Resistance: Passes 300+ rub cycles with a cotton cloth, protecting barcodes from warehouse dust, pallet friction, and handling wear.
Temperature Tolerance: Maintains barcode legibility from 0°C (cold storage) to 60°C (indoor warehouse environments), with optional heat-resistant coatings for up to 100°C.
Cost-Effective Solution: The economy-grade adhesive balances performance and price, providing reliable adhesion to standard substrates without premium material costs.
E-Commerce Fulfillment: Essential for shipping labels, order tags, and warehouse shelf barcodes, supporting high-volume printing with minimal downtime.
Retail Distribution Centers: Used for case labels, carton identifiers, and cross-docking tags, ensuring scannable data throughout the supply chain.
Manufacturing Inventory: Ideal for work-in-progress labels, component barcodes, and quality control tags, withstanding industrial oils and moderate chemical exposure.
Logistics Service Providers: Suitable for express shipping labels, freight tags, and customs documentation, meeting global postal barcode standards (USPS, UPS, DHL).
Q: What barcode symbologies does this support?
A: All major symbologies including Code 128, QR Code, Data Matrix, and UPC, with print resolutions from 203 DPI to 600 DPI.
Q: Can the jumbo rolls be slit to smaller widths?
A: Yes, we offer custom slitting services to any width between 20mm and 1000mm, compatible with most thermal printer models.
Q: How long do the barcodes remain scannable after printing?
A: In standard warehouse conditions (25°C, 50% RH), barcodes remain valid for 12+ months. For outdoor use, consider UV-resistant thermal ribbons.
Q: Is the adhesive safe for food contact?
A: The adhesive meets FDA 21 CFR 175.105 for indirect food contact, suitable for labeling sealed food packaging and shipping cartons.
Product Code: YH20590
Product Name: 75μ Thermal White PP/Acrylic/60g White Glassine
1. Face Stock: Thermal White PP
Caliper (μm). 73±5% GB/T 451.3-2003
Weight (g/㎡): 57±5% GB/T 451.2-2002
2. Adhesive Performance: Acrylic
Initial Adhesion (N): 13.19 FTM 9
20 min.180'Peel Adhesion (N/25mm) : 9.62/10.45 FTM 1
20 min.90'Peel Adhesion (N/25mm): 8.41 FTM 2
Storage Temperature: -15°C to 70°C
Minimum Lakelling Temperature: 10°C
3. Liner: White Glassin
Caliper (μm): 52±5% GB/T 451.3-2003
Weight (g/㎡): 60±5% GB/T 451.3-2003
It can be stored for 1 year at the temperature of 23+2'C and relative humidity of 50+5%
The Thermal Self Adhesive Barcode Label Jumbo Roll Paper is optimized for high-efficiency barcode printing in large-scale logistics and inventory management systems. The label features a 80gsm thermal-sensitive face stock with a uniform coating that ensures consistent barcode density (≥1.5 OD) and contrast (≥70%) across the entire roll. A permanent acrylic adhesive provides reliable bonding to cardboard, plastic, and metal, while a 100gsm high-release liner minimizes jamming in high-speed thermal printers.
Available in jumbo rolls up to 1000mm width and 5000ft length, this material reduces operational downtime by maximizing label yield per roll, making it ideal for distribution centers and manufacturing facilities.
Barcode Optimization: The thermal coating meets GS1 barcode standards for scannability, with a print contrast ratio that ensures first-pass read rates >99.9% in automated scanning systems.
Jumbo Roll Efficiency: Contains 3-5 times more labels than standard rolls, reducing roll change frequency and improving productivity in 24/7 labeling operations.
Abrasion Resistance: Passes 300+ rub cycles with a cotton cloth, protecting barcodes from warehouse dust, pallet friction, and handling wear.
Temperature Tolerance: Maintains barcode legibility from 0°C (cold storage) to 60°C (indoor warehouse environments), with optional heat-resistant coatings for up to 100°C.
Cost-Effective Solution: The economy-grade adhesive balances performance and price, providing reliable adhesion to standard substrates without premium material costs.
E-Commerce Fulfillment: Essential for shipping labels, order tags, and warehouse shelf barcodes, supporting high-volume printing with minimal downtime.
Retail Distribution Centers: Used for case labels, carton identifiers, and cross-docking tags, ensuring scannable data throughout the supply chain.
Manufacturing Inventory: Ideal for work-in-progress labels, component barcodes, and quality control tags, withstanding industrial oils and moderate chemical exposure.
Logistics Service Providers: Suitable for express shipping labels, freight tags, and customs documentation, meeting global postal barcode standards (USPS, UPS, DHL).
Q: What barcode symbologies does this support?
A: All major symbologies including Code 128, QR Code, Data Matrix, and UPC, with print resolutions from 203 DPI to 600 DPI.
Q: Can the jumbo rolls be slit to smaller widths?
A: Yes, we offer custom slitting services to any width between 20mm and 1000mm, compatible with most thermal printer models.
Q: How long do the barcodes remain scannable after printing?
A: In standard warehouse conditions (25°C, 50% RH), barcodes remain valid for 12+ months. For outdoor use, consider UV-resistant thermal ribbons.
Q: Is the adhesive safe for food contact?
A: The adhesive meets FDA 21 CFR 175.105 for indirect food contact, suitable for labeling sealed food packaging and shipping cartons.
The 75μ thermal white PP (polypropylene) is engineered for optimal performance. It's designed specifically for thermal printing, ensuring sharp and clear prints of barcodes, text, and graphics. The white color provides high contrast, enhancing the visibility of the printed content. PP is highly durable, resisting water, chemicals, and tearing. This makes the labels suitable for use in challenging environments, like in food packaging where they may come in contact with moisture or in industrial settings prone to chemical exposure. The 75μ thickness gives it a good balance of flexibility and strength, allowing for easy application on curved surfaces.
The acrylic adhesive forms a strong and long - lasting bond. It adheres well to a diverse range of materials, from plastics to metals and cardboard. Resistant to environmental factors such as temperature fluctuations and humidity, it ensures the label stays firmly in place over time.
The 60g white glassine liner protects the adhesive during storage and transportation. Its smooth surface enables easy release of the label, which is essential for efficient application in high - volume production lines.
It is waterproof, oil-proof and abrasion-proof performance. Apply to simple printing and diecutting blank labels with good die-cutting performance. Can be applied to most barcode printers or electronic scales. Have good color development and general protection. Excellent performance properties on many packaging materials.
The 75μ thermal white PP (polypropylene) is engineered for optimal performance. It's designed specifically for thermal printing, ensuring sharp and clear prints of barcodes, text, and graphics. The white color provides high contrast, enhancing the visibility of the printed content. PP is highly durable, resisting water, chemicals, and tearing. This makes the labels suitable for use in challenging environments, like in food packaging where they may come in contact with moisture or in industrial settings prone to chemical exposure. The 75μ thickness gives it a good balance of flexibility and strength, allowing for easy application on curved surfaces.
The acrylic adhesive forms a strong and long - lasting bond. It adheres well to a diverse range of materials, from plastics to metals and cardboard. Resistant to environmental factors such as temperature fluctuations and humidity, it ensures the label stays firmly in place over time.
The 60g white glassine liner protects the adhesive during storage and transportation. Its smooth surface enables easy release of the label, which is essential for efficient application in high - volume production lines.
It is waterproof, oil-proof and abrasion-proof performance. Apply to simple printing and diecutting blank labels with good die-cutting performance. Can be applied to most barcode printers or electronic scales. Have good color development and general protection. Excellent performance properties on many packaging materials.
It can be used for most traditional printing methods. Due to the thermal characteristics of the product, processing environments exceeding 50°C should be avoided. Inks containing alcohol or volatile organic solvents may cause damage to the heat-sensitive layer. It is recommended to use raw ink processing printing without adding any additives as much as possible. For spot color ink or additive ink, it is recommended to test the ink before printing.
It can be used for most traditional printing methods. Due to the thermal characteristics of the product, processing environments exceeding 50°C should be avoided. Inks containing alcohol or volatile organic solvents may cause damage to the heat-sensitive layer. It is recommended to use raw ink processing printing without adding any additives as much as possible. For spot color ink or additive ink, it is recommended to test the ink before printing.
