    Thermal Transfer Self Adhesive Paper Suitable for Electronic Product Labels

    Model NO :
    YH23928
    Thermal Label Roll is compatible with most thermal printers features high-definition fast color development scratch-resistant.
    Quantity :
    add to cart
    Contact Now
    Product Description
    Product Code:YH23928
    Product Name:70g Thermal Transfer Paper/Acrylic /60g White Glassine
    Face Stock : Thermal Transfer Paper
    Caliper(μm)  :67±5%GB/T 451.3-2003
    Weight  (g/sqm):69±5%GB/T 451.2-2002
    Adhesive Performance : Acrylic
    Initial Adhesion (N):10.72FTM 9
    20 min.180°Peel Adhesion (N/25mm):12.25FTM 1
    20 min.90°Peel Adhesion (N/25mm):10.06/Material tore offFTM 2
    Storage Temperature:-15°C to 70°C
    Minimum Labelling Temperature:10°C
    Liner : White Glassine
    Caliper  (μm) :52±5%GB/T 451.3-2003
    Weight  (g/sqm):60±5%GB/T 451.3-2003
    Product Application: It is an ideal product for high-quality heat transfer printing due to its excellent ink absorption properties of the coating on the surface. Suitable for a variety of high definition, high density bar code heat transfer printing. Most wax bases, wax and resin mixed ribbons are suitable for this product. Typical applications:warehousing, address and shelf labels.
    Printing and processing: The coated surface material can be pre-printed with dots, negative text and solids using flexographic plates and relief plates. The viscosity of the ink should be controlled to avoid excessive viscosity of the ink causing the coating to fall off. Do not print or apply varnish to the area on the label that needs to be printed during pre-printing. Its excellent paper processing performance is suitable for rotary and flat processing methods.
    Storage Condition: It can be stored for 1 year at the temperature of 23±2ºC and relative humidity of 50±5%.





    I. Basic Structure

    The surface material is a special heat transfer paper (with printing coating), combined with eco-friendly water glue and release liner. The layers are closely adhered and easy to peel off, suitable for both automated and manual labeling.


    II. Appearance Characteristics

    The surface is smooth, suitable for heat transfer printing. It enables high-definition barcode and text printing, with rich color reproduction and precise, clear identification content.


    III. Core Performance

    The water-based adhesive has stable viscosity and strong adhesion; it features scratch resistance, waterproof and oil-resistant properties, with a temperature range of -50℃ to 90℃. The printed information remains durable and does not fade.


    IV. Applicable Scenarios

    It is widely used in industrial component traceability, medical consumable identification, supermarket scale labels, logistics barcode labels, and microwave oven applicable labels, etc.


    V. Safety and Compliance

    Environmentally friendly without any odor, the printing coating complies with regulations, meets food contact and medical basic standards, has stable storage properties, and does not release any harmful components.



    Our products are Jumbo rolls of self-adhesive label materials.

    The main face stock materials are:
    semigloss paper / thermal paper / glossy paper / thermal transfer paper / matte white PP / glossy white PP / transparent BOPP / bright silver BOPP /  holographic laser film /  PE, etc.
    These face stock materials can be processed with different glues (such as acrylic glue, hot melt glue, solvent glue, frozen glue) and liners such as glassine, PET,etc. to produce different types of self-adhesive labels to meet various needs.The products are widely used in daily chemical products, electronic products, food and beverage products, etc.

    he main face stock materials are:semigloss paper / thermal paper / glossy paper / thermal transfer paper / matte whitePP/ glossy white Pp /transparent BOPp/ bright silver BOPP/ holographic laser film /PE.

    These face stock materials can be processed with different glues (such as acrylic glue, hot meltalue, solvent glue, frozen glue) and liners such as glassine, PET etc. to produce different types ofself-adhesive labels to meet various needs.The products are widely used in daily chemical products,electronic products, food and beverage products, etc.


     All kinds of recommended products


    FAQ

    Q1:What products do you have?
    A: Jumbo rolls of self-adhesive label materials. The main face stock materials are: semigloss paper,thermal paper, glossy paper, thermal transfer paper, matte white PP, glossy white PP, transparent BOPP, bright silver BOPP, holographic laser film, PE, etc. The products are widely used in daily chemical products, electronic products, food and beverage products, etc.

    Q2: Are you a manufacturer or a trading company ?
    A:100% manufacturer in Guanzghou,China. With nearly 20 years of experience in manufacturering self-adhesive label materials. Near by Guangzhou port and Shenzhen port, China.

    Q3: If I need sample, what l need to do? and how long can l have sample?
    A: lf there is existing product in stock, sample will be sent in 24hrs. lf not, it takes 3-5 days. But if it is special size and requirements, or small order Qty, there will be sample charge. And the express charge will be aforded by customer.

    Q4:How does your factory do regarding quality control?
    A: When all goods finished, there will be 100% inspection before package, and will double verify before shipment.

    Q5:Do you have MOQ?
    A:Our MOQ depends on the raw materal quantity, normally 1.07m*1000m=1070 squre meters(can be precut as per customers' requirements)

    Q6: What info l need to provide if l want to get the price?
    A: Product material, size, color, order Qty, porduct used enviroment, trend terms(FOB or ClF or Ex-work), destination port and other special requirments.

    Q7:What is your payment terms?
    A: 100% T/T before shipment for order amount under US$10,000; 30% T/T advanced,70% balance before shipment for order amount over US$10,000.

    Q8:How do you ship the goods and how long does it take to arrive?
    A: For samples or small orders, we usually ship by DHL, UPS, FedEx ,TNT etc. it usually takes 3-5 days to arrive. Airline and sea-shipping also optional.
